cream filling machine

Cream pepper sauce filling machine high viscosity liquid filler equipment semi automatic pneumatic f

Cream pepper sauce filling machine high viscosity liquid filler equipment semi automatic pneumatic f

Pneumatic Sauce Filling Machine semi automatic horizontal pneumatic filler equipment  (paste filler ,honey filling into jars,gel filling machine, cream filling machine, ointment filler, paste filling machine)

One-head Paste filling machine is on the basis of our paste filling machine series. Transform and create the product on the reference of foreign advanced filling machine technology.
Application Range:

aroview shot for horizontal filling.jpg

Applied in medical, chemistry, foodstuff, pesticides and special industries. It is an ideal equipment for filling the high viscosity fluid. As the machine is working without the electricity, it is very safe and the personal design better meets the demands of morden enterprises.
This machine is semiautomatic piston paste filling machine, without electricity, more safer to operate it.
Advantages:

detailed data horizontal filling machine.jpg

1.Reasonable design, compact shape, simple operation, partly adopt the German FESTO and Taiwan AirTac pneumatic components.
2. The contact part with the material is all made of 316L stainless steel, meet the GMPs requirements.
3. Filling capacity, filling speed can be adjusted, filling accuracy is high.
4. Adopt the device like leak-proof, Anti-drawing and lifting of filling.

Basic parameter of pneumatic filling machines semi automatic:

stainless steel machinery.jpg

Technical Parameter of Model YX-LC Pneumatic filling machine semi automatic:

Model       filling volume     Air consumption       Net weight       Dimensions(mm)

YX-LC-02-15     5-150ml           23L/min                     11kg              L92xW28xH40

YX-LC-02-25      10-250ml         30L/min                    25kg              L102xW30xH40

YX-LC-02-50      10-250ml         44L/min                    28kg              L108xW32xH41

YX-LC-02-100     60-1000ml        87L/min                  36kg               L128xW36xH41

YX-LC-02-250     250-2500ml      160L/min               60kg               L130xW60xH51

YX-LC-02-500     500-5000ml      300L/min               75kg               L130xW60xH51



Working Principle

stainless steel machinery.jpg

Piston Fillers measure and dispense free flowing products - such as thin and dense liquids and paste into a container.

 Each machine is equipped with one or more volumetric pistons. Each filling cycle consists of an intake stroke,

where the product is withdrawn from the hopper or vessel by tube and taken into the product cylinder. The down

stroke commences as soon as the product cylinder has reached its predetermined fill level. The

piston pushes the product out of the cylinder and into the container.

cream filling samples.jpg

packaging for horizontal pneumatic filling machine honey cream pepper sauce filler

packaging for horizontal filling machines.jpg



Warranty & Insurance:

Buyers are responsible for additional tax, customs fee and Duty for importing (if any). Insurance is optional. We are not responsible for package lost or damaged during delivery if they are not insured.

Return Policy

1. If there is something wrong with the product, please contact us within 3 days. Product exchange notified after 3 days may not be honored for replacement.

2. The product MUST be returned in its original presentation package. And the product could be returned only if it is natural broken and it has never been used Please include in the returned package your name, email address, telephone number, and reason for return.

3. Buyer should be responsible for ALL Return shipping costs.

Feedbacks Policy

We appreciate your positive feedbacks and we will promptly do the same; if you are not satisfied with our service, please contact us first to negotiate before you give Neutral or negative feedback. Thanks for your understanding.

Customer Service:

Please contact us any time when you have questions or problems upon our products. Your inquiry will be replied within 24 hours.

PENGLAI INDUSTRIAL CORPORATION LIMITED
