Technical parameters of plane surface containers bottles glue non sticker labeling machine manual 平面ラベリングマシン:
Model YX-PL75

flat surface bottles labeler equipment (1).jpg


This is the configuration of standard machine,the machine can be customized according to customer's special requirement
Applicable Length of Label 10mm~60mm
Applicable Width of Label 5mm~70mm
Applicable product size (L)20mm~200mm
(W)20mm~180mm
(H)0.2mm~75mm
Applicable outside diameter of label roll Φ240mm
Applicable Inside diameter of label roll φ76mm


Accuracy of labeling ±0.2mm
Feeding label speed 5m/min
Labeling speed 15~25pcs/min
Weight (kg) about 67kg
Frequency(HZ) 50HZ
Voltage(V) 220V
Power(W) 145W
Equipment external dimensions(L*W*H) 550mm*420mm*780mm
Air pressure(Mpa) 0.4~0.6Mpa

flat surface bottles labeler equipment (1).jpg

Our Factory since 1992 has been manufacturing the cosmetic&food making and packaging machinery.In these field we have the experience rich enough to solve the questions encountered by our customers from both home and abroad.For more information about various high quality machinery like Model YX-PL75 plane surface containers bottles glue non sticker labeling machine manual 平面ラベリングマシン ,please email via jackdu999@yahoo.com or browse our website http://penglaichina.com.
