US CA customer purchased two sets filling ultrasonic sealing induction sealer automatic for cosmetic food packaging process

Recently our US customer Ruben purchased two sets of machines: one(1*)set of model YX-UF100A tubes filling ultrasonic sealing machine

semi automatic; the other one(1*)set automatic bottles aluminum foil sealing machine ;

After we finished manufacturing of the machines we sent the pictures&manuals&how-to operation videos to our customer for check-out. Due

to the great quality of machines there is not any problem for inspection upon the machines filling sealing .then our customers in USA assigned

their forwarder to ship the goods. Finally we delivered the machines ply-wooden cased to the GUANGZHOU warehouse and offered to our customer

the related docs like PL/CI for clearing custom .

Now the machines is on the board and leaves for CA in the vast ocean .Hope our customer can get the machine ASAP .

Below is the basic information for this win-win international business transaction :

The Purchase order issued from USA buyer

purchase order von customer.jpg

Samples sent from our US customer

ruben tubes samples (3).jpg

Testing videos of model YX-UF100A tubes filling ultrasonic sealing machine semi automatic

Trial run video of model YX-IS1800 automatic aluminum foil induction sealing machine

Wooden case packaging for the machines with marks

wooden case packaging for filling sealing machines.jpg

(tubes filling sealing machine model YX-UF100: Packaging size 1090x1250x1680mm)

aluminum sealing machine in crate.jpg

(automatic aluminum foil sealing machine model YX-IS1800into two small case :automatic induction sealing:670x1300x940MM,
conveyor belt:1590x450x400mm)

Below is the basic description of the two machines

►Model YX-UF100A semi automatic tubes filling ultrasonic sealing machines

close shot of tubes filling sealing machines.jpg

Features of semi automatic tubes filling ultrasonic sealing machines:

 Plastic hose through the tube, the marks, filling, sealing, cutting and out of the tube, the machine packing job completion.

model YX-UF100A touch screen tubes filling sealing machinery

tubes sealing in a row.jpg

Tubes filling sealing machine ultrasonic technology with Touch screen controlling system

►Covers and claddings made in 304 stainless, confirm GMP standard

►Contact parts in SS 304

►Positive filling nozzle. Pneumatic cut off system.( To avoid tailing problem)

►No-tube No-fill /No tube No sealing Hot-air heating of tubes internally and cooling externally to avoid dent at the sealing are PLC control touch screen

►Ferguson indexer

►Panel box which is easy to access

►Both side batch coding 12 characters at most.

►Fill volume from 5ml up to 200 ml. with interchangeable pumps.3ml to 30ml, 30ml to 100ml, & 100ml to 250ml

►Tube diameter: min 10mm – max.50mm.

►Output up 1600to 2,200 tubes per hour.

►Tube counter

►Easy adjustable sealing head

Main Technical Parameters of lotion cream filling ultrasonic sealing machine for plastic tubes:



touch screen for filling sealing machinery.jpg

inside tubes filling sealing machinery semi automatic model



Type

YX-UF100A

Voltage

220v/50Hz/60Hz

Productivity

20-30pcs/min

Dimension

1090x1250x1680mm(L*W*H)

Weight

270kg

Filling Volume

10-300ml

Tube Diameter

10--60mm

Power

2.0KW -3.3KW

Accuracy

±1%

Material

Stainless steel 304

Control

PLC control system

Display

Touch screen display

Bottle Height

2-200(mm)

►Automatic aluminum foil induction sealing machine model YX-IS1800

model YX-IS1800 induction sealing machines automatic.jpg

Application OF MODEL Model YX-IS1800 Automatic linear induction sealing machine aluminum caps electromagnetic sealer

aluminum induction sealing machine.jpg

1) Sealing for PET bottles, PP bottles, PVC bottles, PE bottles, HDPE

bottles, plastic bottles, glass bottles, etc

2) Widely used in cosmetic, drinks, chemical, medical, food industry etc, which

   can highly improve productivity and product quality.

vertical view of induction sealing machines.jpg

pharmaceutical sealer induction sealing.jpg

Features of electromagnetic induction sealing machine model YX-IS1800:

controlling panel for induction sealing machine.jpg

1. Full stainless steel enclosure and integrated frame, digital display, artistic design;

2. Water cooling circulation system, keeping the power of components at a desirable temperature    range for more reliable operation;

3. With under/over-voltage protection, over-current protection, overheating protection etc.

4. High sealing power, fast sealing, designed for high-speed production lines.

Technique Parameter of Model YX-IS1800 automatic inline aluminum foil induction sealing machines:

induction sealer equipment automated.jpg

Rated voltage

AC220V50/60Hz

Machine Net Weight

68kg   50kg

The maximum power

1800W

Cooling Method

Cool Air/water double

cooling way

Sealing diameter

φ15-75mm 15MM-45MM

 30MM-60MM

Bottle Height

20-180mm

Working methods

continue working

Application Scope

Large Patch of Production

Sealing speed

0-200 bottle/min



Packaging Dimension

1600*450*1500mm

Generator size

1450*410*1300mm

Description

Stainless Steel



Balance TT copy for the machine before shipping

TT COPY von US kunde for machines.jpg

Packing list of machines two(2*)sets of filling sealing machine model YX-UF100A &aluminum induction sealing model YX-IS1800

ULTRASOUND SEALING MACHINES FOR usa CUSTOMER.jpg

Warehouse receipt in GUANGZHOU CITY


After-sales service for PENGLAI YX series filling sealing machines






After-sales service &gurantee for cups filling sealing machine rotary model

Guarantee: for all the machine, we have give one year for guarantee.(Excluded from the warranty are problems due to accidents, misuse , misapplication, storage damage, negligence, or modification to the Equipment or its components. ALSO THE EASY BROKEN SPARE PART IS NOT INCLUDED IN THE GUARANTEE)

Installation: after the machine arrive your factory,if you need,our technician will go to your place to install and test the machine and also training your worker to operating the machine (The time of train depend on you worker). The expenses (air ticket ,food , hotel, the travelling fee on your country) should be on your account and you need paid for the technician  USD50 per day. also you can go to our factory to do training.

After service: If you get the problem on the machine ,our technician will go to your place to fixed the machine as soon as possible. The cost should be in your account.(as above).
